Application Specific Batteries

24 V, 36 V and 48 V lithium-ion battery modules, scalable from 0.58 kWh to 37.5 kWh.

The ASB product portfolio includes standardised battery modules in various voltage and capacity levels.

The modules are modular in design, scalable and can be precisely adapted to different technical requirements. Thanks to their clearly structured design, systems can be easily configured and efficiently integrated with certified components and optional accessories.

Downloads

Handbook

USP

Performance & efficiency: Fast charging times and high discharge capacity, even with irregular use.
Durability: High cycle stability for a consistently long service life.
Time advantage: No development costs and short implementation times.

Intelligence & safety: Integrated electronics with optimal cell protection, monitoring and communication.
Energy & economy: High energy density for efficient use, reduced maintenance intervals and low operating costs.

ASB product portfolio

The ASB product portfolio includes modular battery modules in various voltage and capacity ranges. The standardised units are scalable, can be flexibly combined and come with the appropriate certificates.

	VKB	Rated capacity	Nominal voltage	Discharge current	Cyle Life	Charge Temperature	Discharge Temperature	Watt-Hour	Download
EASY BLOCK 24	56650 764 099	22.8 Ah	25.6 V	20 A	10,000 cycles	0 °C to +50 °C	-20 °C to +60 °C	583 Wh	Battery Charger
EASY BLOCK 48	56650 764 098	11.4 Ah	51.2 V	10 A	10,000 cycles	0 °C to +50 °C	-20 °C to +60 °C	583 Wh	Battery Charger
EASY BLADE 24	56654 799 098	58 Ah	25.9 V	31 A	1,200 cycles	0 °C to +45 °C	-20 °C to +55 °C	1.502 kWh	Battery Charger
EASY BLADE 36	56654 799 089	44.8 Ah	37 V	60 A	1,200 cycles	0 °C to +45 °C	-20 °C to +55 °C	1.658 kWh	Battery Charger
EASY BLADE 48	56654 799 092	29 Ah	51.8 V	10.3 A	1,200 cycles	0 °C to +45 °C	-20 °C to +55 °C	1.502 kWh	Battery Charger
EASY BLADE Baby 24 V	56672 742 098	15.8 Ah	25.2 V	17.4 A	1,200 cycles	0 °C to +45 °C	-20 °C to +60 °C	400 Wh	Battery
